IronMan 5/6 Combo Seamless Rollformer

application/pdf iconKWM 5_6 Combo.pdf

 IRONMAN 5/6" SEAMLESS ROLLFORMER


Polyurethane Drive Train
  • Eliminates the need to load coil prior to transportation (less material waste)
  • Rollform 24 gauge steel
  • Eliminates slippage from cold weather and condensation
.002 Hard Chrome Plated Steel Forming Rollers
  • Rollforms all recommended materials with minimal or no adjustment
  • Free-floating forming rollers produce less pressure and allow for more product uniformity
Electrical and Control System
  • Push button entry and exit end controls with safety wiring and "jog" feature
  • 3/4 HP, 110 volt, single phase motor, 13.6 ampere
Structural Steel Frame
  • Welded tubular frame
Modular Turnstile Upright System & Transfer Bars
  • Transfer bars (ease of coil loading)

Specifications:

Power: 3/4 HP, 110 volt, single phase, 13.6 ampere, totally enclosed fan cooled (T.E.F.C.) motor
Dimensions: Length - 122" (309.88 cm), Height - 48" (122.0 cm), Width - 24" (61.0 cm)
Weight: Approximately 1,400 lbs. (635 kg)
Drive: Powered polyurethane drive rollers via chains and sprockets
Shear: 5" - Front pull guillotine, 6" - Front pull guillotine
Speed: Approximately 35 feet per minute
Controls: Push button entry and exit end controls with "jog" feature


Recommended Materials:

  • Maximum width 5" - 11 3/4" to 12"
  • Maximum width 6" - 15"
  • Painted steel - 24 Maximum Gauge
  • Aluminized steel - 24 Maximum Gauge
  • Ternecoat steel - 24 Maximum Gauge
  • Aluminum - .032 Maximum Gauge
  • Copper - 16 oz. 3/4 hard Maximum Gauge

Options:

  • Machine mount cradles
  • Additional runout support stands
  • CE Certified wiring
  • Additional turnstiles
  • Additional spools
  • Alcoa style hook
  • 12 volt, DC power
  • Box gutter
  • Roof flange 1"
  • Trailer riser pad
